Tecno Aluminium/Steel Manual Step 560MM - SPECIAL ORDER

Stock not available in the showroom and will need to be ordered in. The ordering process can take up to 10-14 working days. Please call us on 024954 9996 to check availability

If you need this part shipped to you, please ring to ask about freight costs as this is a custom freight item. 02 4954 9996.

DESCRIPTION

The Tecno Step is fantastic addition to your caravan or motorhomeThese single steps have an Aluminium tread and the frame is all galvanised steel constructionClearance required: 170mm deep when closed, Closed step is 50mm proud of mounting flange, Open step is 300mm proud of mounted flange, Open step tread is 190mm below mounting flange, Overall width of top mounting frame: 560mm

Mounting Hole Spacing (Front to Back/Depth): Approximately 205mm

Mounting Plate Length (Width): Approximately 530mm

SPECIFICATIONS

Spring loaded for very easy operation
1 year warranty.
Model: 450-02140 Coast to Coast, 006507 CAMEC, Nuova
Brand: Tecno - Nuova Mapa
Step Tread 560mm x 210mm
Weight: 5.5kg
Clearance required: 170mm deep when closed
Closed step is 50mm proud of mounting flange
Open step is 300mm proud of mounted flange
Open step tread is 190mm below mounting flange
Overall width of top mounting frame: 560mm
